1. Application

The machine is used for cabling control cable, mining cable, rubber sheathed cable and ABC cable.

2. Processing characteristics

The big bending machine is used to bend the steel plate to the frame structure. Four frame structures share the circle equally, and they are welded together with the big discs on the both sides. Also all the structures are welded to the center thick wall tube. The whole structure is strong and beautiful.

Then the whole structure will be machined on the big horizontal lathe. This horizontal lathe is big enough to machine every part in one step, without changing one end to the other. This process will keep the concentricity of the whole structure, prolong the service life of bearings on the both ends.

This double column vertical lathe is used to turn the big disc for cradle type laying-up machine and the capstan of the stranding machine. This machine can turn and burnish the grooves to protect the cable and keep the same hual-off force.

Dynamic balancing machine is the key producing equipment to produce the fast running wire and cable equipment, especially the rigid frame stranding cage and tubular stranding cage. The machining process of the stranding cage will lead to different eccentric force, which will be detected by the dynamic balancing machine. After corrected the stranding cage will easily meet the high speed rotation requirement and increase the service life.

Electric annealing furnace is indispensable to produce wire and cable making machine, particularly the rigid frame stranding machine and tubular stranding machine. The internal stress of the main stranding cage is great when it's welded together. The internal stress is released strongly by heat treatment. This produce process will ensure that the stranding cage without deformation and fracture to improve internal quality.

3. Main specification

4. Photo

5. Packing photo


6. Our factory and introduction
