Product Details:
Payment & Shipping Terms:
|
| Equipment Name: | Portal Type Pay-off And Take-up | Bobbin Size: | 1600-3150 |
|---|---|---|---|
| Material: | Steel | Power Supply: | As Per User's Request |
| After-Sale Service: | Support | Warranty: | 1year |
| Color: | As Per User's Request | ||
| Highlight: | Portal movable type cable machine,Pay-off and take-up machine with traverse,Cable machine traverse accessory |
||
1. Application
Mainly for the paying off and taking up of wire various kinds of wire and cable production lines.
2. Machine Features
Floor-mounted pay-off stand, suitable for plastic extruders, wire & cable stranding and cabling machines.
Reel traversing design saves floor space and ensures stable cable production.
Automatic tension control, cable diameter/traverse pitch adjustment, position correction and reel loading/unloading.
Reliable mechanical structure and electrical control system for efficient and easy operation.
3. Technical Specifications
3.1 Type: Floor-mounted Pay-off Stand
3.2 Max. Reel Diameter: Ø3150 mm (min. Ø2000 mm)
3.3 Applicable Cable Diameter: Ø20–120 mm
3.4 Pay-off Speed: 5–75 Hz, 5–75 m/min
3.5 Reel Loading/Unloading: Motorized
3.6 Reel Clamping: Motorized double-end clamping
3.7 Brake: Pneumatic disc brake
3.8 Tension Range: 0–20,000 N
3.9 Guide Roller: Ø400 mm, 1 groove + 1 groove + 1 V-groove
3.10 Drive Motor: 11 kW / 15 HP worm gear motor
3.11 Max. Reel Load: 18,000 kg
